SHALLOW MOUNTED BOLLARD

OVERVIEW:
These shallow mounted bollards are of
static type, namely non-removable.
There have been major developments in
the design of bollards that do not need
deep foundations and this product is now
considered the best on the market as
surprisingly it only has a depth of 150mm
and is compliant with PAS68 subsequently CWA 16221 and ASTM
testing standards with an 80km (50mph)
impact speed.

USE:
Static bollards of non-removable, non-lowering type are widely specified by security advisers to prevent vehicles, which may contain explosive devices, parking close to areas of vital importance such as embassies, ministries, IT centres, research laboratories. Many installations are retro fitting which means shallow foundations are a real requirement due to below ground services.

SIZE & CONSTRUCTION:
The bollard height is 1m above ground level and the core diameter 300mm. The bollard is fixed to specially constructed base plate units for concreting into ground. Maximum centres 1.5m.

FINISH:
Steel core with stainless steel shroud. Alternatively black polyurethane sleeve. All other exposed steel surfaces hot dipped galvanised.

INSTALLATION
Bollards are supplied welded to their base plates which are set onto concrete base, maximum 150mm below finished ground level.
